Lodron Hybrid e-Bike

Our e-bike bestseller offers a balanced overall concept and is made for the mountains: robust, rigid, tracks well, agile – with good rolling characteristics, a comfortable sporty sitting position and inbuilt electric motor from 10.5 kg.

DESIGNED FOR
Mountain & Tour
WHEEL SIZE
27,5"/29"
WEIGHT
from 10.5 kg

Individual Design

Choose the colours and components of your bike to create your unique design. Thanks to our flexibility, our know-how and our experience, we can realise every step with the greatest care. Your name in bright green on a blue frame? Anything is possible! We design your new favourite bike together!



Hybrid e-Assist drive

Our hybrid e-bike system combines perfectly sporty cycling with the option of electric motor support. Elegantly hidden in the seat tube, it transfers the effective power of a considerable 110 watts direct to the foot pedal at the push of a button. Only the saddlebag containing the battery would let an expert know that this is an assist bike. Steinbach bikes can also be fitted or retrofitted with the vivax electric drive. With the large 9.3 Ah battery, the drive unit comes to 2.3 kg.



Accessories

Whether for a cycling trip or your daily ride to work, we equip your bike with the perfect accessories. So you’re always safely underway. From pedals to sports drink bottles. Perfectly prepared for that first cycling experience.



Aluminum-Magnesium Frame

The super-light AN6 aluminium-magnesium Hardtail frames are the Steinbach classic. Our roots. The large-volume, multi butted tubes have sophisticated elliptic designs and wall thicknesses of 0.9-1.6 mm. The laboriously produced tube sets are welded by hand. The “smooth-wide” welding technology results in welds that produce a smooth surface without finishing work and are extremely stable.
The geometry results from our years of analysis into how ergonomics helps to increase endurance.




Specification
Specifications
High-End
Premium
Frame set
frame
Lodron Aluminium Magnesium
Lodron Aluminium Magnesium
Lodron Aluminium Magnesium
size
39cm, 43 cm, 48 cm, 53cm, 58cm
39cm, 43 cm, 48 cm, 53cm, 58cm
39cm, 43 cm, 48 cm, 53cm, 58cm
Electric drive
Micromotor 9.3Ah battery
Micromotor 9.3Ah battery
Micromotor 9.3Ah battery
Chainset
Shimano XT 2x12
Shimano XT 1x12
KURBEL: Shimano XT
brake
Magura MT6
Shimano XT
-
fork
Fox 32 A Float SC
Fox 32 A Float SC
-
Handlebars
Steinbach Alu
Steinbach Carbon
-
Stem
Steinbach Alu
Steinbach Alu
-
Seat post
Steinbach Alu
Steinbach Alu
Steinbach Alu
wheels
DT Swiss 331 hand-spoked
Strike Carbon hand-spoked
-
tires
Schwalbe 27,5", 29", 27,5"/29"
Schwalbe 27,5", 29", 27,5"/29"
-
saddle
Steinbach comfort
Steinbach race
-
Weight
10,5 kg
10,5 kg
3,7 kg
Price incl. VAT.
from € 5,290.00
from € 7,090.00
from € 3,690.00

Geometry
geometry
15"
17"
19"
21"
23"
Frame size cm
39
43
48
53
58
Saddle pipe
A
385
432
483
533
584
Saddle pipe
A1
323
370
423
473
524
top tube
B
550
570
590
610
630
Head tube
C
100
105
110
120
135
Chain stay
D
445
445
445
445
435
wheelbase
E
1034
1054
1074
1094
1104,5
seat tube angle
F
73
73
73
73
73
steering angle
G
71,5
71,5
71,5
71,5
71,5

Technologies that impress



Tailor-made
Customised

Each bike is created to meet individual size, ride and comfort requirements. All parts and components are selected to give you the unique ride experience of a Steinbach bike. Your personal Steinbach experience!

Lightweight frame
Lightweight frame

Full-carbon frame with oversized shaped tubes – perfectly designed for maximum rigidity and the highest ride comfort. Internal cables ensure a clean and aerodynamic design. The alu-magnesium Hardtail frame with triple butted tubes also impresses with a classic linear design. The geometry results from our years of analysis into how ergonomics helps to increase endurance.

Hand-spoked wheels
Hand-spoked wheels

By choosing the right tyres, you can achieve better adhesion to the road or maximum grip on rough terrain. Whether proven aluminium or high-end carbon rims – only the best for the rider. The extensively machined hubs, tuned spokes and smoothest bearings are the perfect connection to the ground.

Drive
Drive

Our hybrid e-bike system and Shimano Steps E-8000 are the slimmest, lightest and most powerful electric aids on the market and push boundaries. The systems offer first-class torques, extremely quiet operation, immediate power response and fast charging.

Individual Design
Individual Design

The sky is the limit – choose from over 700 RAL colours and more than 80 decorative colours, in matt or gloss. Create your favourite bike.
